At the heart of the 6.5Ton diesel Crawler Excavator lies a powerful hydraulic system that delivers exceptional digging force and control. Its high-performance hydraulic pumps, valves, and cylinders enable precise movements and smooth operation, allowing operators to dig, lift, and rotate with utmost accuracy and efficiency. This advanced hydraulic system empowers the excavator to tackle a wide range of excavation tasks, from digging foundations and trenches to loading trucks and removing debris.
ME60 Crawler Excavator specification
| Engine brand | Japan Kubota engine |
| Engine Make /Model | Imported/V2607 |
| Power /Rotation speed | 42.4kw(58HP)@2000rpm |
| Number of cylinder | 4 |
| Maximum Travel speed | 2.4/4.3 km/h |
| Width of track shoe | 400mm |
| Number of track shoe per side | 40pcs |
| Number of upper roller per side | 1 |
| Number of bottom roller per side | 5 |
| Standard Bucket capacity | 0.21m³ |
| Swing speed | 11rpm |
| Maximum Grade ability | 35° |
| Maximum Bucket digging force | 48KN |
| Maximum Arm digging force | 35KN |
| Hydraulic system pressure | 28Mpa |
| Machine weight | 6450kg |
| Fuel tank | 87L |
| Hydraulic oil tank | 100L |
| Overall dimension (L*W*H) | 5940mm*1880mm*2570mm |
| Height of cabin | 2600mm |
| Track length on ground(Axle base) | 1990mm |
| Track gauge | 1480mm |
| Minimum Ground clearance | 353mm |
| Swing radius at tail | 1689mm |
| Maximum Digging height | 5499mm |
| Maximum Dumping height | 3845mm |
| Maximum Digging depth | 3808mm |
| Maximum Vertical digging depth | 2983mm |
| Maximum Digging radius | 6128mm |
| Minimum swing radius | 2607mm |
| Maximum Lifting height of blade | 376mm |
| Maximum Cutting depth of blade | 474mm |
