With its sleek and compact design, Baoomax Electric stacker Forklift truck excels in maneuverability, making it an ideal choice for navigating narrow aisles and confined spaces.By eliminating the noise associated with traditional combustion engines, it creates a quieter work environment, reducing distractions and enhancing communication among operators and workers. Also 1.5ton small electric Forklift’s energy efficiency is a key advantage for businesses seeking to reduce operational costs .
1.5 Ton Electric Forklift specification
| Model | FL15EF |
| Power type | Battery |
| Rated load (KG) | 1500 |
| Load center distance(mm) | 500 |
| Driving type | Seat |
| Length With fork L1 (mm) | 3040 |
| length Without fork L2(mm) | 1970 |
| Whole Width B(mm) | 1000 |
| Height no lifting frame H1(mm) | 1960 |
| Top frame height H2(mm) | 2010 |
| Max Height working H3(mm) | 4050 |
| Distance from seat to top light L3(mm) | 1000 |
| Wheel base L4(mm) | 1260 |
| Front overhang Y(mm) | 385 |
| Back overhang L5(mm) | 365 |
| Front wheel tread R(mm) | 1010 |
| Back wheel tread P(mm) | 100 |
| Min Floor clearance F(mm) | 130 |
| Max lifting height H(mm) | 3000 |
| Free lifting height H4(mm) | 40 |
| Fork changing S（mm） | 1040/200 |
| Min Turning radius WA(mm) | 2100 |
| Min Right angle aisle width RA(mm) | 3850 |
| Frame angle a/β | 6/12 |
| Max lifting speed without goods（mm/s) | 300 |
| Max lifting speed with full goods(mm/s) | 260 |
| Max speed without goods（km/h) | 14 |
| Max speed with full goods(km/h) | 13 |
| Max climbing angle(%) | ≤15 |
| Whole weight (kg) | 2650 |
| Driving Wheel | 2/2 |
| Tyre model | Solid tyre |
| Front Tyre | 18×7-10 |
| Rear Tyre | 16×6-8 |
| Hand Brake | Hydraulic Pedal |
| Brake type | M-Hand |
| Battery Volt/ capacity(v/Ah) | 48V/230 |
| Driving motor power (kw) | 6.5AC |
| pump power (kw) | 5.5DC |
